Available in two sizes from 76.2 x 76.2cm to 91.44 x 91.44cm in 225, 680 and 1360 kg capacities.
Easy Washdown & Installation
HIDS Drum Scales are designed and built for industrial environments. Incredibly easy to install and use; just level the deck, attach the included cable to AC power, calibrate (if a C2® compatible instrument, set your reference), verify and begin weighing.
C2® Electronic Calibration
Used with a Hardy weight processor or controller, C2 enables fast, accurate, electronic calibration without test weights. The C2 system reduces downtime for installation or repairs and eliminates test weight related injuries. A small weight verifies calibration.
INTEGRATED TECHNICIAN®
Each scale has built-in INTEGRATED TECHNICIAN (IT) circuitry in the integrated junction box. Coupled with a Hardy controller or instrument, the scale provides diagnostic and troubleshooting tools that read individual weights and voltages from each load cell to aid you in isolating problems and ensure the integrity of your scale system.
Stainless Steel Load Sensors
The heart of any scale is the load sensors. All HIDS Scales come standard with four matched stainless steel, IP67 HISLB load cells calibrated for mV/V and mV/V/ohm. This eliminates the need for corner adjustment and potentiometers in the junction box, allowing a sensor to be replaced without calibration. With a threaded hole into which the load cell foot is attached, the load is applied at a precise location to provide an accurate reading, weighment after weighment.
Rugged, Low Profile Design
With a deck height of only 4cm and 100% end loading, these floor scales enable easy, slide on/slide off access for easy drum handling and three raised sides to ensure the drum is centered on the Scale.
Service By Design
Along with C2 and INTEGRATED TECHNICIAN, HIDS Drum Scales feature a top access plate for quick and easy access to the Hardy 6011 Summing Card, ensuring that general maintenance is easier and more time-efficient.
