The Whirlwind® Mobile Air Classifier

The Whirlwind® Mobile Air Classifier - Sturtevant
The Whirlwind® Mobile Air Classifier effectively removes excess fines from aggregate products bringing materials formerly considered waste materials into specification. The Mobile Air Classifier’s dry separation process eliminates the need for water typically used in washing plants, which is especially important in remote areas where water is not readily available.

The Whirlwind® Mobile Air Classifier is easy to transport with a rugged chassis frame and a heavy duty tri-axle suspension. The Whirlwind® Mobile Air Classifier has three conveyors that hydraulically fold for transport and un-fold for set-up. Raising and lowering of the air classifier is accomplished with heavy duty dual hydraulic cylinders for easy and safe set-up and tear down.

Features & Benefits:

  • The world’s first and only 100% mobile classifying plant with integral collapsible conveyors
  • Portable air classifier goes to any job-site and reduces cost of shipping manufactured sand
  • Easy to set-up, disassemble and transport
  • Compact design reduces transport costs
  • Adjustable controls reduces out-of-specification material
  • Dry process eliminates the need for wash plants, no water needed
  • Lower feed conveyor height eliminates need for intermediate conveyor
  • Built to last: Tough, durable construction means low maintenance

How it Works:

The material to be separated is conveyed up the integral feed conveyor to the top of the Whirlwind® Mobile Air Classifier. The material enters the feed inlet and falls onto the rotating distributing plate. Centrifugal force sends the materials onto the lower distributing plate for even distribution into the airflow. Due to gravity, the larger particles settle into the coarse cone and finer particles are swept upward into the whirling selector blades for further classification. During the secondary separation, oversized particles are spun out of the air flow and drop down into the coarse cone. The air separated coarse material is discharged out of the inner cone through the side spout and onto the discharge conveyor. The discharge conveyor places the coarse material in the coarse stockpile in front of the unit. The selected fines continue through the circulating fan and into the fines cone. Fines drop out   of the recirculated air flow by gravity at the fixed return air vanes and the cycle repeats. The air separated fines are discharged out of the outer cone through the bottom spout and onto the discharge conveyor. The discharge conveyor places the fines material in the fines stockpile on the side of the unit or in a bin/silo for truck load out.

The moisture content of the material will have a determining factor on the production rate and the degree of separation. The Whirlwind® Mobile Air Classifier performs at maximum efficiency with dry aggregate materials. The Whirlwind® processes materials between 3-5% moisture content, but for best results a moisture content of 2-3% or less is preferred.


  • Aggregate
  • Basalt
  • Crushed Stone
  • Granite
  • Gravel
  • Limestone
  • Manufactured Sand
  • Silica Sand
  • Trap Rock
